SWITCHES

• Switch type: Managed
• Switch layer: L3
• Feature: Quality of Service (QoS) support
• 2.5G Ethernet (copper) ports quantity: 8
• 10G Ethernet (copper) ports quantity: 8
• SFP28 ports quantity: 2
• Power connector: AC-in jack
• IPv4 routes: 512
• IPv6 routes: 256
• Virtual LAN features: MAC address-based VLAN, Private VLAN, Voice VLAN
• Number of VLANs: 4093
• Switching capacity: 140 Gbit/s
• Throughput: 372 Mpps
• MAC address table: 16000 entries
• Latency (10 Gbps): 2.27 µs
• Jumbo frames: 12000
• Packet buffer memory: 32 MB
• DHCP features: DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
• Access Control List (ACL) egress: 1023
• Access Control List (ACL) ingress: 511
• Authentication: Guest VLAN, MAC-based authentication
• Authentication type: RADIUS, TACACS+
• Queue scheduling algorithms: Strict Priority Queue (SPQ), Weighted random early detection (WRED)
• Management protocols: SNMP V1, V2, V3
• Routing protocols: OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
• Form factor: 1U
• Product colour: Black
• LED indicators: Yes
• Airflow direction: Front-to-back airflow
• Processor model: ARM Cortex-A57
• Processor frequency: 1800 MHz
• Memory type: DDR4-SDRAM
• Internal memory: 2048 MB
• Flash memory: 512 MB
• Power source: AC
• Power consumption (typical): 133.5 W
• Power consumption (max): 351.5 W
• Power over Ethernet (PoE) power per port: 90 W
• Total Power over Ethernet (PoE) budget: 3314 W
• Power supply: 550 W
• Operating temperature (T-T): 0 - 45 °C
• Storage temperature (T-T): -20 - 70 °C
• Operating relative humidity (H-H): 0 - 90%
• Storage relative humidity (H-H): 0 - 95%
• Operating altitude: 0 - 3000 m
• Non-operating altitude: 0 - 3000 m
• Width: 220 mm
• Depth: 300 mm
• Height: 43.2 mm
• Weight: 2.9 kg
• Cables included: AC, USB Type-C
• Included power plug types: EU, UK, NA
• Compliance certificates: BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
